Specifications
| Type | PG3A | ||
| Rated pressure range | -99kPa~9.99kgf/cm² | ||
| Withstand pressure | 1.5MPa | ||
| Fluid | 空气, 非腐蚀性, 不可燃性 | ||
| Display unit |
正压Air pressure：kgf/cm²
负压Vacuum：kPa
|
||
| Power supply voltage | DC12~24V±10% | ||
| Current consumption | 30mA | ||
| Switch output | Maximum input voltage | DC30V | |
| Maximum load current | 50mA | ||
| Output type |
NPN 输出
|
||
| Output operation | 常开 / 常闭 | ||
| Output mode | 单点模式 | ||
| Hysteresis | Air pressure：±0.05kgf/cm²
Vacuum：±5kPa
|
||
| Indicator accuracy | ±2% F.S. | ||
| Switch ON indicator | 红灯: 输出指示 | ||
| Ambient temperature range | 0~40C° ( 无水露及不结冰情况) | ||
| Ambient temperature range | 作动及保存:35~75%RH( 无水露) | ||
| Weight | 14g | ||
| Accessories |
PSL-03 IO
KPF-O Plug KTSH4-M5M Quick fitting VG-01M |
||
