Completely filled with resin to be IP67 compliant
Improved water resistance and intensity suitable for conveyor lines
*The operation mode can be selected by a switch
*Sensitivity adjustment for fine detection
*Globally compatible PNP types also conveniently provided with stability output
*Optional rigid protective cover(mounting bracket)available
Improved water resistance and intensity suitable for conveyor lines
*The operation mode can be selected by a switch
*Sensitivity adjustment for fine detection
*Globally compatible PNP types also conveniently provided with stability output
*Optional rigid protective cover(mounting bracket)available
Type
|
Detection method
|
Detecting distance | Model | Operation mode |
Output mode |
|||
| NPN Output | PNP Output | ||||||
| Through beam |
7m | GT5RSN | GT5RSPN-N | Light-ON/ Dark-ON selectable (with swithch) |
Open collector output |
||
| GT5RSN-J | GT5RSPNN-J | ||||||
| GT5PN | GT5RPN-N | ||||||
| GT5RN-J | GT5RPNN-J | ||||||
| Polarized retroreflective | 0.03~1.5m | GMR2RSN | GMR2RSPN-N | ||||
| GMR2RSN-J | -- | ||||||
| GMR2RN | GMR2RPN-N | ||||||
| GMR2RN-J | GMR2RPNN-J | ||||||
| Diffuse reflective | 500mm | GSR05RSN | GSR05RSPN-N | ||||
| GSR05RSN-J | GSR05RSPNN-J | ||||||
| GSR05RN | GSR05RPN-N | ||||||
| GSR05RN-J | GSR05RPNN-J | ||||||
| Convergent reflective | 20~50mm | GSZ5RS | -- | ||||
| GSZ5R | GSZ5RPN | ||||||
