Liquid-dripping prevention vacuum device.
Teaching memory dispensing setting model.
Dispense controlled by connected sequencer.
Digitize control panel.
Instant adjustment shot time.
Caution signal.
Teaching memory dispensing setting model.
Dispense controlled by connected sequencer.
Digitize control panel.
Instant adjustment shot time.
Caution signal.
SM-AX Precision Digital dispenser
Specifications
*1.If use external connection and input voltage, it show caution signal and stop.
Specifications
Control method | Electronic/Pneumatic system | |
Power supply | DC24V(Fixture AC100~240V power adapter) | |
Power consumption | Max.17W | |
Air source | Max. 0.99MPa | |
Dispensing pressure | 0.05~0.69MPa | |
Dispensing duration range | 0.010~9.999sec. | |
Operating mode | Time mode (metered shot ) Steady mode (continuous shot) | |
Display section | LED Digital display of air pressure | |
Control signal Port (Foot switch port) |
Shot (input)signal | When select non-voltage contact mode: *1 Capacity over 20mA of N.O. contact When select input voltage mode:DC5~24V |
Shot end signal | Non-Voltage N.O. contact: Load capacity AC250V, 3A / DC30V, 3A |
|
I/O Connect port | Star / Stop (Input) | Input voltage DC10~30V, ON current:more than 3.5mA, OFF current:lower than 1mA. |
Mode / Shotting (Output) | Non-Voltage contact:DC30V, 20mA | |
Vacuum function | Built-in vacuum transducer | |
Operating temperature | +5oC ~ +40oC | |
External dimensions | (W)184x(D)159x(H)78 mm | |
Weight | 1.23kg |
*1.If use external connection and input voltage, it show caution signal and stop.
