NPN/PNP dual output
Simple teaching using a single button
Large easy-to-read display
Mutual interference prevention function
Two types of display options available
Simple teaching using a single button
Large easy-to-read display
Mutual interference prevention function
Two types of display options available
RATING / PERFORMANCE / SPECIFICATION
Power supply | 12 to 24V DC±10% / or less |
Power consumption | Normal mode:770mW or less(32mA or less at 24V) ECO mode:600mW or less(25mA or less at 24V) |
Control output | NPN open collector output / Load current 100mA(30 V DC) or less / Residual voltage:1 V or less PNP open collector output / Load current 100mA(30 V DC) or less / Residual voltage:2 V or less |
Operation mode | Light ON / Dark ON |
Timer | ON delay / OFF delay / ON/OFF delay / One shot / No timer |
Delay timer:1 to 9999 ms (set in milliseconds) | |
Response time | High speed mode:65 µs or less / Standard mode:500 µs or less / Long mode:4 ms or less |
Light source(wavelength) | Four-element (AlGalnp) red LED (660 nm) |
Indicator | Operation indicator, Setting indicator, Light ON / Dark ON indicator : orange LED |
Display | Received light level : 4 digits in red LED (high-speed mode(0 to 3500), standard / long mode(0 to 9999)) Threshold : 4 digits in green LED (high-speed mode (0 to 3300), standard / long mode (0 to 9700)) |
Switch | Teaching and set switch (SET) Switch for threshold adjustment (UP/DOWN) |
Sensitivity setting | 2-point teaching / Max. sensitivity teaching / Full auto teaching / Position teaching |
Sensitivity adjustment function | Provided(manual adjustment) |
Mutual Interference prevention | UP to 8 units (standard / long mode) |
Protection circuit | Power supply reverse connection protection / Output short circuit protection |
Material | Polycarbonate |
Wiring | 2 m attached cable (Outer dimension : dia. 4.2mm) 0.2mm2, 4 cores |
Weight | Approx. 75g |
Accessory | Instruction maual / QR code label for simplified manual |
