Warning lights,easy to monitor.
Small and light.
Manual fast needle cleaning mechanism.
Air blow cleaning design.
Use for discharging small objects.
Aluminum body.
Ccontact point output,easy to monitor.
Small and light.
Manual fast needle cleaning mechanism.
Air blow cleaning design.
Use for discharging small objects.
Aluminum body.
Ccontact point output,easy to monitor.
| Ion generation | Conrona discharge | |
| Voltage at discharging pin | High-frequency AC | |
| Static elimination time *1 (±1000V►±100V) |
Approximate 3sec | |
| lon balancing | ±15V | |
| Air volume | 11~16CFM(0.31~0.45 M3/min) | |
| Ozone volume | 0.007ppm or less | |
| Control for discharging suspension | Power input (DC10V~30V) | |
| Warning output | Fan stop | YES |
| Discharge error | YES | |
| Discharging signal | Output contact signal (NPN) (50mA) (Discharging ON) |
|
| Ambient temperature | 0~40oC(indoor) | |
| Relativ humidity | 35%~75%，non-condensing | |
| Power input | DC24V ± 5% | |
| Current consumption | 200mA | |
| Dimension | (W)68x(H)78x(D)43 mm | |
| Weight | 1.56kg | |
| Accessories | I/O (KIL-01-1M) Anti-slip mats Instruction manual Warranty |
|
*1.Measured with maximum air speed and at a location centered in the air output and 200mm away from the fan.
